2023 Kawasaki Mule 4010, Call for E-Pricing

Features

• Engine 617cc liquid-cooled
• 4-stroke OHV 90° V-twin
• Bore x Stroke 76.0 x 68.0 mm
• Compression Ratio 10.3:1
• Fuel System Fuel injection: Mikuni AC34
• Ignition Magneto & transistor
• Starting Electric
• Lubrication Forced lubrication wet sump
• Transmission 2-speed automatic forward/reverse
• Final Drive Gear selectable 2WD/4WD
• dual-mode differential
• Frame Ladder type tubular steel
• Front Suspension / Wheel Travel
• Independent MacPherson strut (3.9 in)
• Rear Suspension / Wheel Travel
• Semi-independent De Dion axle (2.8 in)
• Steering Rack and pinion with Electric Power Steering
• Rake / Trail 7.5° / 35 mm
• Steering Angle (L/R)47° (IN) / 34° (OUT) 47° (IN) / 34° (OUT)
• Front Tires 23 x 11.00-10
• Rear Tires 23 x 11.00-10
• Front Brakes Dual hydraulic drums
• Rear Brakes Dual hydraulic drums
• Parking Brake Mechanical drum
• Dimensions (LxWxH)(116.7 x 62.0 x 75.8 in)
• Wheelbase (73.6 in)
• Road Clearance (6.9 in)
• Seat Height (34.1 in)
• Curb Mass** (1433 lb)
• Fuel Capacity 24 litres
• Tread (F/R)(45.7 in) (46.5 in)
• Turning Radius (11.2 ft)
• Cargo Bed Dimensions (LxWxH) (46.3 x 51.6 x 11.4 in)
• Cargo Bed Capacity (800 lb)
• Seating Capacity 2
• Vehicle Load Capacity (1327 lb)
• Towing Capacity (1200 lb)
• Lighting 2x halogen headlights
• Warranty 36 months
• Kawasaki Protection Plus 12 / 24 / 36 / 48 months
